CO2 Cylinder Filling System


CO2 Cylinder Filling System

Specifications

Frequency 50-60hz
Voltage 220-380v
Power Source Electric
Phase Single, Three Phase
Volume 100 liters to 5000 liters
Temperature (-)20°c to (-)50°c

The SSGLA CO2 cylinder filling system has been designed to accurately fill CO2 cylinders by weight. Two filling stands and twin fill control box are included as standard.

The SSGLA CO2 cylinder filling system has been developed as a universal unit to accurately fill high pressure CO2 cylinders by weight. The filling rate is 800 kg/hr and the filling pressure is up to 130 bar. This system comprises of a low to high pressure liquid CO2 transfer pump, two electronic weighing indicators with weighing platforms, filling stands and quick connect filling heads and twin fill control box.

Application :

  • To fill liquid CO2 into high pressure CO2 cylinders
  • To fill fire extinguishers with CO2
  • While one cylinder is being filled the other one is being prepared for filling.
